Reduce cardinality levels to improve performance

Power BI employs several compression mechanisms to reduce the size of data, the details of which are outside the scope of this book. One way to decrease the data size, which we cover next, is by reducing the cardinality of columns by changing data types or the default summarization.

Changing data types

In Power BI, two data types can be used for decimal numbers:

  • Decimal number Can store more than four decimal places
  • Fixed decimal number Can only store up to four decimal places

If your data contains more than four decimal places for some values and you don’t need that level of precision, you should change the data type to Fixed Decimal Number to save space.

Another way to change the cardinality levels is to split decimal number columns into pairs of whole numbers and decimal numbers, which should be done as close to the data source as possible. Whole numbers can be of any range, whereas decimal numbers should be between 0 and 1. These two columns can then be aggregated by using SUMX in the following fashion:

Click here to view code image

Full number =
SUMX(
    ‘Fact table’,
    ‘Fact table'[Whole number] + ‘Fact table'[Decimal number]
)

Although you’ll get two columns instead of one, in many cases you’ll see improvements in cardinality levels and, as a result, a decrease in the data model size. For the same reasons, in Power BI it’s best practice to split Date/Time columns with Time components into two: Date and Time. This is because you are increasing the number of duplicates in each column, and therefore the column is more efficiently stored in memory.

Some text columns, such as invoice numbers that are stored as text, can also sometimes be reduced in size. For example, if your fact table contains a column with invoice numbers, which always have the INV prefix and eight numbers that follow it, such as INV01234567, you can remove the INV prefix and change the data type of numbers from Text to Whole Number. If the prefix is inconsistent, you can split it and move it to a different column. This is because storing whole numbers is usually more efficient than storing text.

Exam Tip

You should be able to recognize models that would benefit from splitting columns and selecting different data types.
